14-pin (12 pins at 5 Amp/250VAC and 2 pins at 13 Amp/250VAC) electrical module |
|
|
- Precious-metal-plated contact pins
- Anodized aluminum
- Delrin®.
|
|
|
12 pins @ 5 Amp/250VAC & 2 pins @ 13 Amp/250VAC |
|
|
-20 ｰF - 150 ｰF (-28.9 ｰC - 65.6 ｰC) |
|
|
|
Custom Application QC Models |
|
|
|
|
There are no Cables associated with this module.
|
|
| 9630-20-KM14.pdf |
KM14 Module Drawing
|
|
|
None currently available. See your Account Representative for more information.
|
| 9120-KM14-T |
Tool side 14-pin module with (12) pins at 5 amps and (2) pins at 13 amps
|
| 9120-KM14-M |
Master side 14-pin module with (12) pins at 5 amps and (2) pins at 13 amps
|
|
